Top Printhead Assembly Parts List
ITEM
PART NO.
DESCRIPTION
QTY
1
05625033
PRINT HEAD HOUSING, LOWER
1
2
05625012
ASSEMBLY, LATCH PRINT HEAD
1
3
05581161
FAN, PRINT HEAD HARNESSED
1
4
05585005
SCREW, SPECIAL HEAD LOCK
2
5
05581111
POT, CONTRAST CONTROL
1
6
05991572
ROLL PIN, 3/32 X 3/8
2
7
05625040
PRESSURE ADJUSTER
1
8
05625021
BUSHING, SPRING MOUNT
1
9
05625032-1
PIN, SPRING GUIDE
1
10
05991604
SPRING, COMPRESSION C0300-0380-500-M
1
11
05990329
E-RING, 7/32
1
12
05990079
10:32 X 1/4 CAP SCREW
1
13
05625129
ASSEMBLY, PRINT HEAD MOUNT
1
14
05625026
LOCK PIN, HD
1
15
05990019
6:32X1/4 B.H. SCREW
1
16
05625020
SPRING, PRINT HEAD RETAINER
2
17
05357040
PLATE, SPRING CAM, LONG
2
18
05357036
PLATE, SPRING CAM, MEDIUM
2
19
05625043
CLIP, HOLD DOWN
1
20
05625041-1
KNOB, CLIP
1
21
05991593
SCREW, 6-32 X 3/16 LG BUTTON HEAD
1
22
05625036
PIN, PRINT HEAD PIVOT
2
23
05625039
STICKER, CONTRAST POT
1
24
05990192
6:32 X 1/2 BUTTON HEAD SCREW
2
25
05990051
8:32 X 3/8 CAP SCREW
2
26
05990513
TIE WRAP, TY523M SMALL
1
27
05991597
SPRING, EXT
2
28
05625010
TURN BAR, INK
1
29
05990055
8:32X3/8 F. H. SCREW
2
30
05621124
CABLE, PRINT HEAD 700, BOTTOM
1
