User’s Manual—SNAP™ 700 Printer 143
Classification: Avery Dennison - Public
Platen Roller Assembly Parts List
ITEM
PART NO.
DESCRIPTION
QTY
1
05581130
SENSOR, OPTICAL SLOTTED, HARNESSED
1
2
05990014
2:56 HEX NUT
2
3
05625037
SHAFT, SWING ARM
1
4
05990090
10:32 X 3/8 BTN. SCREW SOCKET HEAD
1
5
05625042-1
ASSEMBLY, SWING ARM
1
6
117903
BEARING-PLATEN
6
7
05625015
SHAFT, PLATEN ROLLER
1
8
05625046
SPACER, SWING ARM GUIDE
1
9
05990327
SNAP RING, 5/16 "E" RING
2
10
05625014
ROLLER, MOLDED, PLATEN, RED
1
11
05990067
WASHER, #8 SAE
1
12
05990068
WASHER, #8 LOCKWSAHER
1
13
05991454
8-32 X 1/4 THUMB SCREW
1
14
05991608
SPRING, EXTENSION
1
