Drive Assembly Parts List
ITEM
PART NO.
DESCRIPTION
QTY
1
05624016
BRACKET, END DRIVE
2
2
05999001
R6FF BEARING
2
3
05624039
BRACKET, STRIPPER WIRE MOUNT
1
4
05624017
ROLLER, GRIT (MAIN DRIVE)
1
5
05624020-1
SHAFT, IDLER ROLLER
1
6
05624190-1
ASSY, FEED ROLLER
1
7
05624022
BRACKET, STRIPPER, LOWER
1
8
05990281
WASHER, 1/2X3/4X.015 SHIM
2
9
05990328
MUST BE ROHS SNAP RING, 1/2 "E" RING
2
10
05624021-1
PLUG, SPRING LOCK
2
11
05990136
1/4:20 X 1/4 KNURLED CUP POINT
4
12
05989979
10:32 X 1 KNURLED CUP POINT
1
13
05990104
10:32 E-S NUT
1
14
05105023K
IMPRESSION ADJ KNOB/SS KIT
1
15
05990055
8:32X3/8 F. H. SCREW
10
16
05448010
STATIC BRUSH
1
17
05990066
8:32X1/4 BTN. SCREW
4
18
05990079
10:32 X 1/4 CAP SCREW
2
19
05624046
BRACKET, STRIPPER UPPER
1
20
05624178
COVER, FEED GUARD, SNAP 700
1
21
05624015
BRACKET, BASE, DRIVE MODULE
1
22
05991626
COMPRESSION SPRING, .360 OD X .059 WIRE X .69
2
