Avery Dennison SNAP 700 - Page 153

User’s Manual—SNAP™ 700 Printer 153
Classification: Avery Dennison - Public
Nip Roller Assembly Parts List
ITEM
PART NO.
DESCRIPTION
QTY
1
05624023
BRACKET, NIP ROLLER MOUNT
1
2
05584033
BRACKET, NIP ROLLER OUTER
1
3
05999098
BUSHING, 3/16 X 1/4 X 3/8
2
4
05624024
ROLLER, NIP DRIVE, MOLDED
1
5
05624025
ROLLER, NIP
1
6
05999165
BUSHING, 3/16 X 1/4 X 1/4
1
7
05999076
BEARING, 3/16 X 1/4 X 5/8 OIL NS IMPREG BUSHING
1
8
05990325
SNAP RING, 3/16 "E" RING
4
9
05991523
SPRING, COMP 500/600 NIP ASSEMBLY
2
10
05990424
4-40 X 3/8" SH CAP SCREW
2
11
05624038
BRACKET, STRIPPER
1
12
05448010
STATIC BRUSH
1
13
05991373
8-32 X 1/4 PAN PHILLIPS
2
14
05991454
8-32 X 1/4 THUMB SCREW
2
15
05991377
10-32 X 3/4 PAN PHILLIPS
2
