User’s Manual—SNAP™ 700 Printer 155
Classification: Avery Dennison - Public
Knife / Drive Motors Assembly arts List
ITEM
PART NO.
DESCRIPTION
QTY
1
05594004
SHAFT, NIP ROLLER DRIVE
1
2
05584028
GEAR, NIP 26T, 32P
1
3
05584027
GEAR, IDLER 22T, 32P
2
4
05624037
GEAR, NIP IDLER, ALTERED
1
5
05990326
SNAP RING, 1/4 "E" RING
2
6
05990327
SNAP RING, 5/16 "E" RING
4
7
05587017
STANDOFF, KNIFE MOTOR
3
8
05245026
STEPPER MOTOR, HARNESSED
2
9
05990080
10:32 X 3/8 CAP SCREW
6
10
05991642
DRIVE, BEAM COUPLING
1
11
05587018
ASSEMBLY, KNIFE DRIVE SHAFT
1
12
05581130
SENSOR, OPTICAL SLOTTED, HARNESSED
1
13
05585016
GEAR, 38T DRIVE 300 DPI
1
14
05991422
4-40 X 1/4 PAN HD PHILLIPS
2
15
05990006
4:40 X 1/4 CAP SCREW
1
16
117902
GEAR-PLATEN
2
