Cooling Fans Assembly Part List
ITEM
PART NO.
DESCRIPTION
QTY
1
05621237
KIT, FRAME ASSEMBLY, SNAP 700
1
2
05621206-2
BRACKET, MCB SUPPORT
1
3
05621007
BRACKET, EXIT FAN CHUTE
1
4
05991372
6-32 X 1/4 PAN PHILLIPS
4
5
05621004
BRACKET, EXIT FAN MOTOR
1
6
05621134
FAN, HARNESSED 12V
1
7
05581104-1
FAN, 12V HARNESSED
1
8
05991638
SCREW, 6-32 X 1.250 PHCS
6
9
05621006
BRACKET, AIR DEFLECTOR
1
10
05991379
10-32 X 3/8 PHPS
2
