User’s Manual—SNAP™ 700 Printer 165
Classification: Avery Dennison - Public
Stacker Assembly Parts List (Sheet 1 of 2)
ITEM
PART NO.
DESCRIPTION
QTY
1
05628010
FRAME, STACKER, 700
1
6
05588029
BRACKET, DIODE MOUNT, FRONT
1
7
05588031
COVER, LABEL SENSOR
2
11
05628003
ASSY, PLATFORM MOUNT
1
12
05991378
10-32 X 3/8 PHILLIPS FLAT HEAD SCREW
2
13
05628005
ASSY, PLATFORM LABEL
1
14
05990325
E-RING, 3/16
2
15
05628006
SHAFT, LOCK
1
16
05990486
SNAP RING, 3/8 E-RING
1
17
05991439
SPRING, PIN LOCK
1
18
05996159
SWITCH ROCKER, SPDT
1
21
05989986
4-40 ES NUT
3
22
05581177
HARNESS, DOWN STACKER ASSY, PROGRAMMED WITH
GEAR
1
36
05628033-1
COVER, DOWN STACKER, 700
1
37
05991442
8-32 X 3/8 PHILLIPS FLAT HEAD SCREW
2
39
05628012
SPACER, STACKER SLIDE
2
