Stacker Assembly Parts List (Sheet 2 of 2)
ITEM
PART NO.
DESCRIPTION
QTY
ITEM
PART NO.
DESCRIPTION
QTY
1
05628010
FRAME, STACKER, 700
1
21
05989986
4-40 ES NUT
3
2
05628004
BRACKET, STACKER MOUNT
1
22
05581177
HARNESS, DOWN STACKER ASSY,
PROGRAMMED WITH GEAR
1
3
05990273
WASHER, #10 BELLEVILLE
1
23
05991372
6-32 X 250 PHILLIPS PAN HEAD SCREW
2
4
05990104
10-32 E-S NUT
2
24
05990038
6-32 HEX NUT
2
5
05990148
1/4-20 ES NUT
1
25
117954
GEAR-RIBBON 75T
1
6
05588029
BRACKET, DIODE MOUNT, FRONT
1
26
117955
GEAR-RIBBON 54T-15T
1
7
05588031
COVER, LABEL SENSOR
2
27
05990327
E-RING, 5/16
3
8
05588028
BRACKET, DIODE MOUNT REAR
1
28
05991367
E-RING, 9/64
1
9
05991455
10-32 X 5/8 THUMB SCREW
1
29
05990051
8-32 X 3/8 SHCS
4
10
05588001A
PLATFORM SLIDE, ALT
1
30
05991419
DRIVE, SPROCKET #25, 16T
2
11
05628003
ASSY, PLATFORM MOUNT
1
31
05588037
ASSY, CHAIN TENSION
1
12
05991378
10-32 X 3/8 PHILLIPS FLAT HEAD SCREW
2
32
05991418
SPROCKET, STACKER, 10T
2
13
05628005
ASSY, PLATFORM LABEL
1
33
05991419A
SPROCKET, STACKER 16T ALTERED
1
14
05990325
E-RING, 3/16
2
34
05990058
8-32 X 1/4 KNURLED CUP POINT
2
15
05628006
SHAFT, LOCK
1
35
05990069
8-32 HEX NUT
8
16
05990486
SNAP RING, 3/8 E-RING
1
36
05628033-1
COVER, DOWN STACKER, 700
1
17
05991439
SPRING, PIN LOCK
1
37
05991442
8-32 X 3/8 PHILLIPS FLAT HEAD SCREW
2
18
05996159
SWITCH ROCKER, SPDT
1
38
05628011
CHAIN, STACKER DRIVE
1
19
05991510
BALL BEARING , 16mm O.D. x 8mm I.D. FLG
2
39
05628012
SPACER, STACKER SLIDE
2
20
05628002
SHAFT, MAIN DRIVE
1
