User’s Manual—SNAP™ 700 Printer 67
Classification: Avery Dennison - Public
knife. The Gold color spring is on the inboard end and the Light Blue spring
is on the outboard end of the assembly.
8. Remove the Bridge Blade, Knife Output from the Stationary Knife by
removing the two 8-32 x ¼ BHCS.
9. Re-Install this Bridge Blade onto the new Stationary Knife.
10. Properly dispose of the used knife blades.
Caution: Do not mix new and used knife blades as they
will cause premature ware and shorten their life. A chip or
a nick in the blades may damage a new blade on start up.
