Specification T1689 Technical Manual Rev 07
DELTA Rectifier Module MV3000 Air Cooled DELTA
Page 52
2.9.2.12 Heat Dissipation
The heat dissipation for a DELTA rectifier module will vary depending upon the drive in which it is used.
Losses
The losses for this module may be calculated approximately using:
‘Dirty air’ losses = 2.4 x Total d.c. output current.
‘Clean air’ losses = 90 W maximum.
2.9.2.13 Weight
The weight of each Rectifier Module is listed in Table 2–24.
Module type
Weight
kg
lb
GDR391
30.5
67
GDR633
48
105
GDR721
37.0
82
GDR872
51.5
114
GDR1168
62.0
137
Table 2–24. – Rectifier Module Weights
2.9.2.14 Acoustic Noise
The acoustic noise generated by the DELTA rectifier module itself is negligible. The acoustic noise generated
will be from the fan module MVC3014-4001 and will be specific to each application due to location, air routing
and the use of any grills or baffles. See Section 2.11.1.4
