SURFACE | MONITORS SECTION
the closing command of the loudspeakers. That is possible to choose one or more microphones to cut the
loudspeaker output of the CR “Control Room” by following this path:
MENU / AUDIO / INPUTS / MIC / SPK-CUT
(OFF, ST, CR, CR+ST)
When you select CR, press down the knob to confirm the selection and the CR will show up in yellow color.
When you open the associated source with a CUT function you will see it will MUTE CR Loudspeakers output
to prevent LOOP audio and the SPEAKER icon at LCD will start plinking.
ATT. (attenuation) MODE: It helps reduce acoustic flux from flowing into the speakers.
Is it possible to decrease the output of the loudspeaker to -40, -30, -20, or -10 dB.
EX.: If we want to reduce the sound coming out of the speakers by 40 dB less than the current value, then
we have to choose -40. The same thing if we want to reduce the current volume when opening any of the
microphones with a value of 10 decibels, then we have to choose -10 and confirm the selection by pressing
the button around until the selection color changes to yellow.
The CUT mode is triggered by the change from OFF to ON of a microphone source to which it has been set
closing of the loudspeaker.
As shown in the MENU this function (CUT) is associated only with the loudspeakers, to avoid LARSEN effects
“feedback loop” from occurring between the nearby loudspeakers and On-Air microphones.
On the other hand, if you need to MUTE the loudspeakers manually just PRESS the volume knob down.
PRESS the volume knob a second time or rotate it to activate the loudspeaker output and amplification or
attenuation. The status of MUTE-SPK is indicated by a red cross on the SPEAKER icon.
TALKBACK
Here is where can disable/enable the TALKBACK communications in the loudspeaker’s output. Normally the
talkback is used to communicate between the mixer man and the people in the studio via headphones. This
option gives you the possibility to hear the people talking in TALKBACK the studio via the CR (Control Room
loudspeakers).
MENU / AUDIO / OUTPUTS / MONITOR / SPK-CRM / TALKBACK
(OFF, ON)
