12
Switching between summer
and winter time
automatic
Radio clock optional: external DCF77-Receiver
Event buffer min. 780 events
Transmission protocols SCTM, IEC 60870-5-102, automatic protocol recognition
alternative: Modbus RTU
Internal modem optional: PSTN max. 9600 Baud
alternative: ISDN, LAN/Ethernet
External modem GSM/GPRS: UniMod GSM-4
PSTN: UniMod 01/I
ISDN: UniMod 01/ISDN
LAN/Ethernet: UniMod Ethernet
Bluetooth: UniMod Radio BT
Transmission speed: Service
Data (Com1)
Modem (Com2)
9600 Baud (fix)
300, 600, 1200, 2400, 4800, 9600 Baud (programmable)
up to 9600 Baud
Transmission mode Full duplex
Program protection Via password and protection switch
Certification by PTB Publication No. 3785 and 4208 of PTB Braunschweig and
Berlin
Remote programming Not permitted
Auxiliary voltage 60VDC – 270VDC and 85VAC – 265VAC
Power consumption Max. 20VA
Enclosure Housing for panel mounting or 19”-rack
Connectors Pluggable terminals with screws
Number of terminals 60 (inputs and outputs) + 3 (auxiliary voltage)
Dimensions (W × H × D) Housing for panel mounting: ca. 175mm × 300mm × 150mm
19”-rack: ca. 215mm × 130mm × 265mm
Ancillary equipment Programming software DLXPARA, programming cable,
PC-Card (memory card)
