Baer DLX - 19-Rack; Figure 11, Sealing Arrangements for 19-Rack; Figure 12, Dimensions of 19-Rack

41
4.1.2 19"-rack
At the 19“-rack the keyboard and the back are sealed using sealing screws
(four at front, six at back). The complete unit then can be plugged into the
19“-rack and fixed using four knurled screws (see M3 thread at front).


 The eight sealing screws at the sides must not be removed!
To uncover the parameter switch remove the sealing screws at the
back.
Figure 11, Sealing arrangements for 19”-rack
Figure 12, Dimensions of 19”-rack
