3.10 Outputs
The DLX data logger (remote metering device) can have up to 6 freely pro-
grammable outputs, which are available in wipe technology (Out1 to Out4,
type IAW) and as mechanical relays (Rel1 and Rel2). Corresponding light
emitting diodes (LED) in the display show the state of each output (output
closed or active: LED is lit). The following functions are possible:
•
Total 1 to 4:
pulse output for total registers (only with Out1 to Out4)
•
MPA1 and 2:
output indicating the end of registration period Tm1 or Tm2
•
RSTA:
reset output
•
Alarm1 and 2:
output for warning messages (Alarm1) and device faults
(Alarm2)
•
TRA1 to 4:
Rate control outputs. After a unit restart the following fac-
tory settings are active:
Energy rate TRA1 TRA2 Demand rate TRA3 TRA4
AT1 0 0 MT1 0 0
AT2 1 0 MT2 1 0
AT3 0 1 MT3 0 1
AT4 1 1 MT4 1 1
where: state "1": output is active (closed), output LED is lit
state "0": output is non active (open), output LED is off
•
Log1 to 4:
logic outputs, used to forward signals to externally con-
nected devices. Control of the logic outputs is performed
via remote data retrieval.
•
In1 to 16:
pulse inputs can be redirected (1 to 1) to outputs (for ver-
sion 1.04.00 and up). No conditioning of pulse lengths or
signal type is performed.
These functions can allocated to more than one output at the same time
(pulse multiplication exists for version 1.04.00 and up).
