B 10
Scroll List
The scroll list can only display values for information purposes!
For the purpose of easy interpretation you can assign a text of max. 20
characters to each address (and 5 characters for each unit).
Register addresses for the scroll list
Explanation of the register addresses abbreviations and placeholders:
cc input (counter) 01 = input 1
02 = input 2
…
16 = input 16
t Tariff rate 0 = total (no rate: sum of all energy tariff values)
► From DLX version 1.04.00 up you can also display
maximum demand values without tariff rate (totals;
t := 0 to 4 for addresses 3xtxx, 4xtxx and 5xtxx).
For cumulated maximum demand: t := 1 to 4
1 = rate 1
2 = rate 2
3 = rate 3
4 = rate 4
pp positive sum 01 = sum 1 (+ or -)
nn negative sum 02 = sum 2 (+ or -)
03 = sum 3 (+ or -)
04 = sum 4 (+ or -)
MP registration period 1 = period Tm1/MP1
2 = period Tm2/MP2
