6.1.2 Light emitting diodes (LED)
The LED’s show whether the DLX is receiving or transmitting pulses,
whether faults have occurred and whether the unit is currently using the
PC-Card:
The light emitting diode(s)
•
"In1" to „In16"
represent the state of the corresponding pulse input;
Exception: analogues inputs for firmware version from 1.06.00 and up: the
LED’s show whether the DLX is receiving a data telegram (every second).
•
"Al1"
blinks when an alarm of class1 (warning) has occurred (see „Fault Dis-
plays“, page 97).
•
"Al2"
blinks when an alarm of class 2 (device fault) has occurred (see „Fault
Displays”, page 97).
•
"M"
is active during access to the PC-Card (memory card).
•
"Out1" to "Out4"
are lit when the corresponding output is closed (active).
•
"Rel1" and "Rel2"
show the current status of the corresponding relay..
•
"Ctl1" to "Ctl7"
show the current status of the corresponding control input.
•
"Com2/Modem", "Com1/Data" and "Service"
are lit during communica-
tion on these interfaces.
