32
3.7.3 Rate control inputs
The rate control inputs TR1 to TR4 determine (if desired and if present in
the customer specific hardware configuration) the currently active energy
rate and maximum demand rate. The usage of inputs and the correlation of
input states to rates can be programmed freely (settable).
The factory default settings use TR1 to switch between two energy and
demand rates.
TR1 TR2 TR3 TR4
Energy rate mask
Demand rate mask
TR1 TR2 TR3 TR4 Energy Demand
0 - - - AT1 MT1
1 - - - AT2 MT2
The state of deactivated control inputs (in our example: TR2, TR3 and
TR4) has no influence on the rate control (no matter whether the state
is 0 = open or 1 = closed).
If other combinations are desired, they can be programmed (see user man-
ual of DLXPARA).
Example: rate control for 4 energy rates and 2 demand rates, controlled by TR1, TR2
and TR3.
TR1 TR2 TR3 TR4
Energy rate mask
Demand rate mask
TR1 TR2 TR3 TR4 Energy Demand
0 0 0 - AT1 MT1
1 0 0 - AT1 MT2
0 1 0 - AT2 MT1
1 1 0 - AT2 MT2
0 0 1 - AT3 MT1
1 0 1 - AT3 MT2
0 1 1 - AT4 MT1
1 1 1 - AT4 MT2
