7.9.4 Set cumulative counter
How to get there
Press the -key three times when in menu item “Maintenance” and then
press the key. The function "Set cumulative counter" is password
protected.
Password protection
The function “Set cumulative counter“ can be activated with either the
password for PARAMETERS or the password for SET. After entering the
correct password (see “Password input“ on page 56) the function will be
executed.
What can be done?
You can modify the cumulative initial counter value for all inputs (I) and for
all total registers (S).
How to do it
Use the and keys to select the inputs (I01 to I16) or the summation
unit (S01 + to S04-). Then press the key to move the cursor to the
rate selection. Use the and keys to select the desired rate (rate 1 to 4
or the rateless register). Now press the key to move the cursor to
the register value. Use the and keys to modify the individual digits (9
digits for version 1.04.00 and higher) and the key to confirm your in-
put and to move to the next digit. Use the
key to abort the function at
any stage.
7.9.5 Initiate maximum reset
How to get there
Press the -key four times when in menu item “Maintenance” and then
press the key. The function "Initiate maximum reset" is password
protected.
Password protection
The function “Initiate maximum reset“ can be activated with either the
password for PARAMETERS or the password for RESET. After entering
the correct password (see „Password input“ on page 56) the function will be
executed.
Executing a reset
The function will store the maximum demand values (together with the date
and time of occurrence) as well as the cumulative and the current counter
values. The display will show the message “Reset is being executed”. for a
couple of seconds. Afterwards the display returns to showing the standard
display. The first line will now show the symbol " " for the duration of the
reset blocking time.
