A 14
22m
-xx Current status for cos(φ) (for version 1.04.00 and up)
M:=6
to
m:=7
m: Registration period (m:=6,7)
6 Registration period MP1
7 Registration period MP2
xx: desired cos(φ)
00 cos(φ)1
01 cos(φ)2
Table value: b7
b6
b5
b4
b3
b2
b1
b0
b7b6b5b4b3b2b1b0: Status
b0 to b7 usually have the value „0“. Exception:
b1 = ‘1‘ on over flow of the demand register
Example: 0 0 0 0 0 0 1 0
Expl.: Demand register has flown over.
23m
-xx Counter status for the previous registration period (for version 1.04.00 and up)
m:=0
to
m:=1
m: Registration period (m:=0,1)
0 Registration period MP1
1 Registration period MP2
xx: desired value (Counter/Total)
00 Counter 1
01 Counter 2
... etc.
15 Counter 16
64 positive Total 1
65 positive Total 2
66 positive Total 3
67 positive Total 4
80 negative Total 1
81 negative Total 2
82 negative Total 3
83 negative Total 4
Table value: b7
b6
b5
b4
b3
b2
b1
b0
b7b6b5b4b3b2b1b0: Status
b0 to b7 usually have the value “0”. Exceptions:
b0 = ‘1‘ on overflow of the energy register (999999999)
b1 = ‘1‘ on overflow of the demand register (99999999)
b2 = ‘1‘ when the signal condition monitoring has been triggered,
no data telegrams or errors from analogue input for at least 60 se-
conds
b3 = ‘1‘ on parameter change for the energy register
b4 = ‘1‘ if the register is currently in test mode
Example: 0 0 0 0 0 0 0 1
Expl.: Energy register has flown over.
