A 18
4rt -xx Reset: counter value at the time of the reset for t:=5 to t:=9
(modified from version 1.04.00 and up)
t:=5
to
t:=9
r: desired reset index (r:=0 or r:=1 to 9):
0 current counter values
1 last reset
2 second last reset
... etc.
t: energy rate (t:=4 for total and t:=5 to 8 for rate 1 to 4)
up to version 1.03.08
4 Total (Sum of all rate values)
5 energy rate 1
6 energy rate 2
... etc.
t: energy rate (t:=5 for total and t:=6 to 9 for rate 1 to 4)
from version 1.04.00 and up
5 Total (sum of all rate values)
6 energy rate 1
7 energy rate 2
... etc.
xx: desired value (Counter/Total)
00 Counter 1
01 Counter 2
... etc.
15 Counter 16
64 positive Total 1
65 positive Total 2
66 positive Total 3
67 positive Total 4
80 negative Total 1
81 negative Total 2
82 negative Total 3
83 negative Total 4
Table value:
d d d d d d d d
dddddddd: The counter value at the time of the reset
Example:
1 2 3
4 5 6 7 8
Expl.: At the time of the reset the counter value was 12345678.
