3.3 Modbus register addresses
List of supported register addresses:
• Type A: 16-bit values unsigned (one register = 2 bytes: 0 to 65535)
• Type C: 32-bit values unsigned (two registers = 4 bytes: 0 to 4294967295)
For all 32-bit values / type C (energy counters, maximum demand (energy
feed)- und maximum values):
Address “Addr” := High-Word (2 bytes)
Address “Addr + 1” := Low-Word (2 bytes)
Modbus
Address
(Type)
SIGLON
Address
(+40001)
Description Correspondent
SCTM-Address
Status Registers
9900 (C) 49901C Modbus address (device ID)
9902 (C) 49903C Version (integer, e.g. 10500 for 1.05.00) 700-01
9904 (A) 49905A Version day and time: year,
e.g. for 29.06.2009: Addr. 9904=2009
700-02
9905 (A) 49906A Version day and time: month*100+day
e.g. for 29.06: Addr. 9905=0629 (629)
700-02
9910 (C) 49911C Time (seconds since 01.01.1990) 000-00
9912 (C) 49913C Timestamp for last reset (seconds) 109-xx
9914 (C) 49915C Timestamp for last Tm1 (seconds) Newest (PP-01)
9916 (C) 49917C Timestamp for last Tm2 (seconds) Newest (PP-02)
9918 (A) 49919A Registration period length Tm1 (minutes) 701-00
9919 (A) 49920A Registration period length Tm2 (minutes) 701-00
9920 (A) 49921A Device status of Tm1
2
700-2y, y=1
9921 (A) 49922A Device status of Tm2
2
700-2y, y=2
9922 (A) 49923A State of logic inputs
4
660-nn, nn=0..3
Meter Values
xx00 (C)
1
4xx01C Pulse count for an input 130-xx
xx02 (C) 4xx03C
Counter value total actual
4rt-xx, r =0, t=5..9
xx04 (C) 4xx05C Counter value T1 actual
xx06 (C) 4xx07C Counter value T2 actual
xx08 (C) 4xx09C Counter value T3 actual
xx10 (C) 4xx11C Counter value T4 actual
xx12 (C) 4xx13C
Counter value total last reset
4rt-xx, r =1, t=5..9
xx14 (C) 4xx15C Counter value T1 last reset
xx16 (C) 4xx17C Counter value T2 last reset
xx18 (C) 4xx19C Counter value T3 last reset
xx20 (C) 4xx21C Counter value T4 last reset
xx22 (C) 4xx23C
Counter value total last Tm1
10t-xx, t=0..4
xx24 (C) 4xx25C Counter value T1 last Tm1
xx26 (C) 4xx27C Counter value T2 last Tm1
xx28 (C) 4xx29C Counter value T3 last Tm1
xx30 (C) 4xx31C Counter value T4 last Tm1
xx32 (C) 4xx33C
Counter value total last Tm2
11t-xx, t=0..4
xx34 (C) 4xx35C Counter value T1 last Tm2
xx36 (C) 4xx37C Counter value T2 last Tm2
xx38 (C) 4xx39C Counter value T3 last Tm2
xx40 (C) 4xx41C Counter value T4 last Tm2
xx42 (C) 4xx43C
Counter value current total actual
5rt-xx, r=0, t=5..9
xx44 (C) 4xx45C Counter value current T1 actual
