A 45
2
Device status in the registration period:
S
15
S
14
S
13
S
12
S
11
S
10
S
9
S
8
S
7
S
6
S
5
S
4
S
3
S
2
S
1
S
0
S
0
: Restart
S
1
: Parameter change
S
2
: Manually change of meter value
S
3
: Power failure
S
4
: Warning
S
5
: Error
S
6
: Setting the time (manually) or time correction via the radio clock
(more than 1 minute)
S
7
: Test mode
S
8
: Change of state of one LOG control input
4
S
9:
Summertime switching
Example:
0 0 0 0 0 0 0 0 0 0 0 1 1 0 0 1
Description: In this measuring period: power failure longer then 200 ms:
S
0
: Restart
S
3
: Power failure
S
4
: Warning
3
Register status in the registration period:
0 0 0 0 0 0 0 0 b
7
b
6
b
5
b
4
b
3
b
2
b
1
b
0
b
7
b
6
b
5
b
4
b
3
b
2
b
1
b
0
: Status messages
Standard: b
0
to b
7
: ‘0‘.
Messages: b
0
= ‘1‘ Overflow energy register (more then 999999999)
b
1
= ‘1‘ Overflow maximum demand register (more then 99999999)
b
2
= ‘1‘ When the signal condition monitoring has been triggered, no data
telegrams or errors from analogue input for at least 60 seconds
b
3
= ‘1‘ Parameter change by the user: energy register
b
4
= ‘1‘ Register: test mode
4
State of the logical inputs:
L1 L2 L3 L4 0 0 0 0 0 0 0 0 0 0 0 0
Example:
0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Log1 =0, Log2=1, Log3=0, Log4=0 (40 00
Hex
:= 16384
Dec
)
