64
What will be shown ?
After entering the menu item the DLX will display the demand values, en-
ergy values or increments of the last registration period Tm1/MP1 or
Tm2/MP2 (if present) for all inputs (I01 to I16), totals (S01 to S04), appar-
ent demand (X01 or X02) and cos(
ϕ
) (P01 or P02) that have been stored. It
will also show the device status (Gs, see appendix A, SCTM Protocol).
Load profile values that have rolled over (exceeded the maximum value of
the register) are indicated by a leading FF, e.g. a value of 18000 is shown
as FFFF8000 (if 4 digits have been programmed for this value, see buffer
options in DLXPARA manual). Values for periods of a power failure are
shown as “--------“.
Use the -key or the -key to switch between registration periods.
Use the -key to move the cursor to the next parameter, then use the
or the key to change the parameter value.
