Barber-Colman MACO Series User Manual

1640-IN-031-C-08 Page 99 of 104
MACO Series Controller Installation
Eurotherm/Barber-Colman
Emissions
(reference standards CISPR 16 and CISPR 16-1)
Port Frequency Range Limits
Enclosure 30 MHz to 230 MHz 40 dB (mV/m) quasi-peak,
measured at 10 meters
230 MHz to 1 GHz 47 dB (mV/m) quasi-peak,
measured at 10 meters
AC Mains 0.15 MHz to 0.5 MHz 79 dB (mV) quasi-peak
66 dB (mV) average
0.5 MHz to 5 MHz 73 dB (mV) quasi-peak
60 dB (mV) average
5 MHz to 30 MHz 73 dB (mV) quasi-peak
60 dB (mV) average
Discrete Inputs (192 maximum per rack)
Points per Card: 24 (standard density)
48 (high density)
AC Inputs
Operating Specs: 100 to 240 Vac
On Voltage: ≥92 Vac
Off Voltage: ≤30 Vac
Input Current: 15 mA @ nominal voltage
Indicator: LED per Input
Isolation: Optically Isolated as a Group
DC Inputs
OperatingSpecs: 12 to 24 Vdc
On Voltage: ≥10 Vdc
Off Voltage: ≤ 3 Vdc
Input Current: 10 mA @ 24 Vdc
Indicator: LED per Input
Isolation: Optically Isolated as a Group
Discrete Outputs (192 maximum per rack)
Points per Card: 16 (standard density)
24 (high density)
AC Outputs
Operating Specs: 100 to 240 Vac, 125/250 VA (pilot duty)
(external voltage)
Minimum Load: 50 mA
Maximum Load: 1 Amp
Maximum Leakage: 5 mA
Fuse: 2 Amp Fuse per Output
Indicator: Neon per Output (load side)
Maximum Output
Current per Card: 16 Amps
(Enclosed Systems)
Maximum Output
Current per Card: 8 Amps
(Open Frame Systems)
Isolation: Optically Isolated (in groups of 4)
