Instruction Manual w VERTICUS 5 Compressor Units
D-33
B-CONTROL II TROUBLESHOOTING
No:
Fault message Cause Remedy
0 Final pressure sensor 1
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
1 Final pressure sensor 2
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
2 Intake pressure sensor
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
3 Oil pressure sensor defective or
wrong sense of rotation
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
Motor power connection wrong interchange 2 of 3 phases in compressor
switch box. Refer to compressor
operation manual
4 Interm. pressure sensor 1st
stage defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
5 Interm. pressure sensor 2nd
stage defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
6 Interm. pressure sensor 3rd
stage defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
7 Interm. pressure sensor 4th
stage defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
8 Crankcase pressure sensor
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
9 Pressure dew point sensor
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
10 Level sensor niveau gas balloon
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
11 Temperature sensor Kühlluft
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
12 Temperature sensor LS
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
13 Temperature sensor defective Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
14 Temperature sensor 2nd stage
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
15 Temperature sensor 3rd stage
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
16 Temperature sensor 4th stage
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
17 Temperature sensor gas outlet
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
18 Cooling water temp. sensor
defective
Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
