Instruction Manual w VERTICUS 5 Compressor Units
D-34
No: RemedyCauseFault message
19 Spare sensor Ch. 19 defective Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
20 Spare sensor Ch. 20 defective Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
21 Spare sensor Ch. 21 defective Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
22 Spare sensor Ch. 22 defective Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
23 Spare sensor Ch. 23 defective Broken wire or short circuit Check wiring acc. to schem. diagram
Sensor defective Replace sensor
24 spare
25 spare
26 Safety final pressure 1 reached Final pressure 1 setting wrong Check pressure and sensor settings
Final pressure sensor 1 defective See fault message 0.
27 Safety final pressure 2 reached Final pressure 2 setting wrong Check pressure and sensor settings
Final pressure sensor 2 defective See fault message 1.
28 Intake pressure low Gas supply pressure low Readjust gas supply. Refer to
compressor operation manual
Inlet shut-off valve geschlossen. Inlet shut-off valve öffnen.
29 Intake pressure high Gas supply pressure high Readjust gas supply pressure. Refer to
compressor operation manual
30 Öldruck low Oil level low Top up oil. Refer to compressor
operation manual
Oil pump defective Contact BAUER service dept.
Wrong direction of rotation Interchange 2 of 3 phases in compressor
switch box. Refer to compressor
operation manual
31 Interm. pressure 1st stage min. Pressure valve 1st stage defective Contact BAUER service dept.
Compressor block defective
32 Interm. pressure 1st stage max. Suction valve 2nd stage defective Contact BAUER service dept.
Connection (pipe, cooler, interm.
separator) between 1st and 2nd stage
clogged
33 Interm. pressure 2nd stage
max.
Suction valve 3rd stage defective Contact BAUER service dept.
Connection (pipe, cooler, interm.
separator) between 2nd und 3rd stage
clogged
34 Interm. pressure 3rd stage max. Suction valve 4th stage defective Contact BAUER service dept.
Connection (pipe, cooler, interm.
separator) between 3. and 4. stage
clogged
35 Interm. pressure 4th stage max. Suction valve 5. stage defective Contact BAUER service dept.
Connection (pipe, cooler, interm.
separator) between 4. and 5. stage
clogged
