Measured values
Oper.hours. 0 h
Start cycles 0 cycles
Final pressure 1
Final pressure 2
Intake pressure
Page 1
Measured values
Page 2
Oil pressure
Temp. last stage
Cooling air temp.
Crankcase pressure
bar
Measured values
Page 3
Interm. pressure 1
Interm. pressure 2
Interm. pressure 3
Interm. pressure 4
Instruction Manual w VERTICUS 5 Compressor Units
A-32
Measured values (Page 1)
Page 1 shows:
- Operating hours
- Start cycles
- Final pressure 1
- Final pressure 2
- Intake pressure
Display of the analogue measured values is by bar graph
with additional digital display. The blue vertical bar shows
the current measured value. The red area of the value axis
shows the scale area over or under the parametrised
threshold value (depending on the existing threshold
value).
Measured values (Page 2)
Page 2 shows:
- Oil pressure
- Temperature last stage
- Cooling air temperature
- Crankcase pressure
The measured values are displayed as per Page 1, with a bar
graph.
Measured values (Page 3)
Page 3 shows:
- Intermediate pressure 1
- Intermediate pressure 2
- Intermediate pressure 3
- Intermediate pressure 4
The measured values are displayed as per Page 1, with a bar
graph.
