Final pressure >
Intake pressure >
Gas balloon level >
System settings >
Set values
Final pressure 1
Compressor stop
Compressor start
Final pressure
Compressor stop
Compressor start
Intake pressure
Instruction Manual w VERTICUS 5 Compressor Units
A-34
Compressor Setup
The "Final pressure" box is always shown. The boxes intake
pressure or gas balloon level only if the individual sensors
are registered.
Final pressure
Setting for final pressure 1 & 2.
Final pressure 2 is only displayed if the final pressure sen
sor2 is also registered.
Intake pressure
You must take account of the fact that the compressor stop
value is under the compressor start value. The compressor
thus stops if the intake pressure falls below the parame
trised value and starts again if the pressure rises above the
compressor start value.
