Instruction Manual w VERTICUS 5 Compressor Units
A-68
Compressor unit
V 15.1-7.5 V 15.1-11 V 15.11-11 V 18.1-11 V 18.1-15........... ... .... .. ....
Compressor block IK15.1 IK15.1 IK15.11 IK18.1 IK18.1............ ....... ....... ...... .......
Delivery
b)
370 l/min 450 l/min 450 l/min 520 l/min 600 l/min ................... .... .... .... ....
13.0 cfm 15.8 cfm 15.8 cfm 18.2 cfm 21 cfm............................ ..... ..... ..... .....
Pressure setting, pressure switch according to order............................
Pressure setting, final pressure safety valve according to order...................
Speed 1,050 min
-1
1,320 min
-1
1,320 min
-1
1,140 min
-1
1,320 min
-1
...................... ... ... ... ...
Drive input 6.9 kW 9.6 kW 9.8 kW 10.4 kW 12 kW.................. ....... ....... ....... ......
Drive motor power 7.5 kW 11 kW 11 kW 11 kW 15 kW........... ....... ....... ....... .......
Weight
c)
, approx. 410 kg 410 kg 410 kg 420kg 435 kg............ ....... ....... ....... .......
13.1.2. Compressor blocks
Compressor block IK12.14
.................................
No. of stages 4......................................
No. of cylinders 3....................................
Cylinder bore 1st stage 105 mm..............................
Cylinder bore 2nd stage 105/88 mm.............................
Cylinder bore 3rd stage 28 mm.............................
Cylinder bore 4th stage 12 mm.............................
Piston stroke 40 mm......................................
Intermediate pressure 1st stage 3,4 ... 4,2bar.......................
Intermediate pressure 2nd stage 14 ... 18 bar......................
Intermediate pressure 3rd stage 53 ... 82 bar......................
Compressor block oil capacity 2.8 l........................
Oil pressure 4.5 bar $1,5 bar.......................................
Direction of rotation (viewing at flywheel) counter-clockwise..............
Compressor block IK150
.................................
No. of stages 4......................................
No. of cylinders 4....................................
Cylinder bore 1st stage 120 mm..............................
Cylinder bore 2nd stage 60 mm.............................
Cylinder bore 3rd stage 32 mm.............................
Cylinder bore 4th stage 14 mm.............................
Piston stroke 50 mm......................................
Intermediate pressure 1st stage 2 ,4... 3,7 bar.......................
Intermediate pressure 2nd stage 14 ... 17 bar......................
Intermediate pressure 3rd stage 58 ... 75 bar......................
Compressor block oil capacity 6 l........................
Oil pressure 4.5 bar $1,5 bar.......................................
Direction of rotation (viewing at flywheel) counter-clockwise..............
Subject to change without prior notice
