Instruction Manual w VERTICUS 5 Compressor Units
A-69
TECHNICAL DATA (Cont.)
Compressor block IK15.1.................................
No. of stages 4......................................
No. of cylinders 4....................................
Cylinder bore 1st stage 110 mm..............................
Cylinder bore 2nd stage 60 mm.............................
Cylinder bore 3rd stage 32 mm.............................
Cylinder bore 4th stage 14 mm.............................
Piston stroke 50 mm......................................
Intermediate pressure 1st stage 2,9 ... 3,5 bar.......................
Intermediate pressure 2nd stage 14 ... 16 bar......................
Intermediate pressure 3rd stage 50 ... 69 bar......................
Compressor block oil capacity 6 l........................
Oil pressure 4.5 bar $1,5 bar.......................................
Direction of rotation (viewing at flywheel) counter-clockwise..............
Compressor block IK15.11.................................
No. of stages 4......................................
No. of cylinders 4....................................
Cylinder bore 1st stage 110 mm..............................
Cylinder bore 2nd stage 60 mm.............................
Cylinder bore 3rd stage 32 mm.............................
Cylinder bore 4th stage 12 mm.............................
Piston stroke 50 mm......................................
Intermediate pressure 1st stage 2,0 ... 2,3 bar.......................
Intermediate pressure 2nd stage 16 ... 17 bar......................
Intermediate pressure 3rd stage 71 ... 96 bar......................
Compressor block oil capacity 6 l........................
Oil pressure 4.5 bar $1,5 bar.......................................
Direction of rotation (viewing at flywheel) counter-clockwise..............
Compressor block IK180.................................
No. of stages 4......................................
No. of cylinders 4....................................
Cylinder bore 1st stage 130 mm..............................
Cylinder bore 2nd stage 60 mm.............................
Cylinder bore 3rd stage 32 mm.............................
Cylinder bore 4th stage 14 mm.............................
Piston stroke 50 mm......................................
Intermediate pressure 1st stage 3,0 ... 4,3 bar.......................
Intermediate pressure 2nd stage 16 ... 18 bar......................
Intermediate pressure 3rd stage 63 ... 86 bar......................
Compressor block oil capacity 6 l........................
Oil pressure 4.5 bar $1,5 bar.......................................
Direction of rotation (viewing at flywheel) counter-clockwise4..............
Subject to change without prior notice
