Baumer EA Series User Manual

Baumer_EAx_EtherNetIP_EN_MNL 66/81 www.baumer.com
02.20
Instance Attribute 103 - Gear Factor Numerator
This instance attribute is used to set the numerator of the gear factor of the encoder.
Value range
1..8192
(for "MT16ST13" device variant)
1..4096
(for "MT16ST14" device variant)
1..16384
(for "MT13ST18" device variant)
All other values not allowed.
Default value
8192
(for "MT16ST13" device variant)
4096
(for "MT16ST14" device variant)
16384
(for "MT13ST18" device variant)
Instance Attribute 104 - Gear Factor Denominator
This instance attribute is used to set the denominator of the gear factor of the encoder.
Value range
1..65535
(for "MT16ST13", "MT16ST14"
and "MT13ST18" device variants)
All other values not allowed.
Default value
1
(for "MT16ST13", "MT16ST14" and "MT13ST18" device
variants)
Instance Attribute 105 - Diagnostic Logbook
The logbook contains diagnostic data.
Instance Attribute 106 - Device Temperature
This instance attribute contains the device temperature value in the value range from -128 to 127 degrees
Celsius.
Instance Attribute 107 - Preset Request Value
This instance attribute contains the value which will be used as preset value when a preset is triggered by
the push button.
Value range
0 to total measuring range -1
Content of Instance Attribute 17 - Total
Measuring Range in Measuring Units
Instance Attribute 108 - Raw Position
This instance attribute contains the raw position value (without the influence of scaling).
