Baumuller b maXX BM3400 Series User Manual

Cable ontrol voltage supply / signals D.13T
D.10 Ciruit mains - devie
device cross section
1)
maximum length connection to de vice
BM340X,
BM341X
4 x 1 to 2.5mm
2
(AWG 16 - 12)
1)
user-defined with/without wire end ferrule
(plug-in terminal)
BM3422 4 x 8 to 16mm
2
(AWG 16 - 12)
1)
user-defined with/without wire end ferrule
(plug-in terminal)
1)
Possible cr oss section: For UL conform machines/installations you must use UL cer tified circuit cables.
D.11 Ciruit devie - motor
device cross section
1)
maximum length
2)
connection to device
BM340X,
BM341X
4 x 1 to 2,5mm
2
(AWG 16 - 12)
2)
max. 50m flexible cable without wire end fer-
rule (plug-in terminal)
BM3422 4 x 8 to 16mm
2
(AWG 16 - 12)
1)
max. 50m with/without wire end ferrule
(plug-in terminal)
1)
Possible cross section: Use a screened circuit line, shield coverage > 85%. The installing of the cables is
user-defined. For UL conform machines/installations you must use UL certified circuit cables.
2)
Only for Baumüller c a bles with this maximum length and by usage of a Baumüller mains filter you can
assume, that the limits of the EMC regulations are complied with.
D.12 Cable ontrol voltage supply / signals
device cross section
1)
maximum length
2)
connection to device
BM34XX ≤ 0.5mm
2
user-defined without wire end ferrule (plug-in
terminal)
1)
The laying of the cables is user-defined
2)
Any kind of cable can be used, the length of the cable does not influence the compliance to the EMC
regulation.
Instrution Manual b maXX ® BM3400 189
Doument No.: 5.07013.03 from 206
