Baumuller b maXX BM3400 Series User Manual

Connetion diagrams 6.12T
6.12.1 Devies aording to typ e key V1
1 2 3 4 5 6
+24V +24V N_Ein B_Ein −24V −24V
X100
2 3 4
KS_P 1 KS_S +24V_R −24V_R
X102
1W1 PE 1U1 1V1
4 3 2 1
X202
Art.−Nr. 00395837BM3411−L3FB−AECB−O
Figure 6.12: Type plate for a device HS1 according to type key V1
The character string BM3411-L3FB-AECB-0 marks the device accordingly «Type key version 1» from page 37.
The middle and the end of the specification contain 4 digits.
Devices, which were delivered from 06/2007 on have a type plate with a 2D-code:
Baumüller Kamenz GmbH
Nordstraße 57 D−01917 Kamenz
www.baumueller.de
Made in Germany
1 2 3 4 5 6
+24V +24V N_Ein B_Ein −24V −24V
X100
2 3 4
KS_P 1 KS_S +24V_R −24V_R
X102
PE 1W1 1V1 1U1
4 3 2 1
X202
BM3411−L3FB−AECB−OTyp:
Eingang: 3x400V (480V) AC 50/60Hz
Ausgang: 3x0...370V (450V) AC, 3x3.5A 0..400Hz
00395837Art.−Nr.: Ser.−Nr.: 506013589
Compact Servo Drive
Figure 6.13: Type plate for a device HS1 acc. to type key V1 with 2D-code
CAUTION
The following c an occur, if the safety instruction is not complied with:
• Damage to property
The danger is: electricity.
Assure yourself at the selection of plug assignments, that the differentiation of both type key
versions wa s considered.
Instrution Manual b maXX ® BM3400 73
Doument No.: 5.07013.03 from 206
