Additional data referring to water-cooled brake resistors
Instruction handbook b maXX BM4400, BM4600, BM4700
Document No.: 5.12008.07 Baumüller Nürnberg GmbH
108
of 358
3.6
Figure 51: Braking cycle
P
D
Average continuous brake power of one cycle
P
Dmax
Maximum continuous brake power, see ZTechnical data brake resistors–
on page 106
n Number of brake operations within one cycle
P
S_1
to P
S_n
Brake peak power, numbered in chronological order
t
on_1
to t
on_n
Brake time periods
t
off_1
to t
off_n
Off time periods, between the brake time periods
T
cycle
total cycle
C
1
, C
2
, C
3
Constants, see ZTechnical data brake resistors– on page 106

brake
on_1
off_1 on_2
off_2
on_n
off_n
on_1
cycle
