Baumuller BM4400 - Encoder Modules Slot;Position a and B

Design and Operation
Instruction handbook b maXX BM4400, BM4600, BM4700
Document No.: 5.12008.07
123
of 358
4
4.2.3 Encoder modules slot/position A and B
There can be different encoder modules In slot/position A and B, see also ZType code–
from page 126.
Here is a choice of encoders, which you can connect to the encoder modules:
NOTE!
On
ly 2 analog outputs can be parametrized or linked even more than one AIO module
is available.
Identification Encoder module Encoder type Connectable encoders
examples
BM4-F-ENC-01
Resolver module Resolver, transmission ratio: 0.5
BM4-F-ENC-11
Resolver reduced level Resolver, transmission ratio: 0.28
BM4-F-ENC-21
Resolver module
replaces BM4-F-ENC-01
Resolver, transmission ratio: 0.5
BM4-F-ENC-02
Sine-cosine encoder 
module with Hiperface
®
inter-
face
Sine-cosine encoder singleturn Stegmann
SCS60/70
Stegmann
SRS50/60
Sine-cosine encoder multiturn Stegmann
SCM50/60
Stegmann
SRM50/60
BM4-F-ENC-12
Sine-cosine encoder 
module with Hiperface
®
inter-
face without termination in
communication
Sine-cosine encoder singleturn Stegmann
SCS60/70
Stegmann
SRS50/60
Sine-cosine encoder multiturn Stegmann
SCM50/60
Stegmann
SRM50/60
BM4-F-ENC-03
5V-square wave incremental
encoder module
5 V-square wave incremental
encoder, RS422 output signals
(TTL)
Heidenhain
ROD 426
SickSteg-
mann DRS60
BM4-F-ENC-04
Sine-cosine incremental
encoder module with zero-
point sensing
5 V sine-cosine encoder, output sig-
nals ~1Vss
Heidenhain
ROD 486
Hengstler 
RIS 58
BM4-F-ENC-05
Sine-cosine encoder 
module with EnDat
®
2.1
interface
Sine-cosine encoder singleturn
Sine-cosine encoder multiturn
Length measurement systems
Heidenhain
ECN 413
EQN 425
LC 481
Heidenhain
ECN 113
EQN 1325
LC 181
BM4-F-ENC-06
Encoder module with 
EnDat
®
2.2 interface
Encoder for absolute position sens-
ing with SSI interface
Heidenhain
ECN 1325
singleturn
Heidenhain
EQN 1337
multiturn
BM4-F-ENC-07
Sine-cosine encoder 
module with SSI interface
Sine-cosine encoder, output signals
~1Vss, external encoder supply
SIKO
AEA111
