7.10.4 Requirements for the screwing
X101 (SELV/PELV) Max. cross-section
of connection
Connection
technology
Load capacity
Brake BM4412
BM4413
BM442X
1.5 mm
2
Plug-in contact X101-1 bis X101-4:
min. 0.1 A, max. 0.5 A
BM4414
BM443X
BM463X
1.5 mm
2
Plug-in contact X101-1 bis X101-4:
min. 0.1 A, max. 1.0 A
BM444X
BM464X
1.5 mm
2
Plug-in contact X101-1 bis X101-4:
min. 0.1 A, max. 4.0 A
BM445X
BM446X
BM447X
BM465X
BM466X
BM47XX
1.5 mm
2
Plug-in contact X101-1 bis X101-4:
min. 0.1 A, max. 8.0 A
if you consider UL508C:
max. 4.0 A
X102 (option)
Safety relay
Max. cross-section
of connection
Connection
technology
Load capacity /
voltage level
(SELV/PELV) 1.5 mm
2
Plug-in contact see 
ZC.5 Technical data safety
relay module– on page 350
X103 (0ption)
Safety relay
Max. cross-section
of connection
Connection
technology
Load capacity /
voltage level
(SELV/PELV) 1.5 mm
2
Plug-in contact see 
ZC.5 Technical data safety
relay module– on page 350
NOTE!
Follow the mentioned torques in ZFigure 87– on page 186 and in ZFigure 90– on
page 189 to ensure an adequate conductivity.
