Baumuller BM4400 - Page 192

DC link
1C1 and 1D1
2)
Ballast
Ba+ and Ba-
1)
Max. cross-sec-
tion of connec-
tion
Connection
technology
Torque Load capacity
1C1 and 1D1
2)
Ba+ and Ba-
3)
BM441X 2.5 mm
2
Plug-in contact - see ZElectrical
data of the uni-
versal units–
from page 63
BM442X 4.0 mm
2
Screw terminal min. 0.5 Nm
max. 0.6 Nm
BM443X
Generation 1
4)
10 mm
2
Screw terminal min. 1.2 Nm
max. 1.5 Nm
BM443X
Generation 2
4)
BM463X
25 mm
2
Screw terminal min. 2 Nm
max. 2.3 Nm
BM444X
BM464X
50 mm
2
Screw terminal min. 6 Nm
max. 8 Nm
BM445X
BM465X
BM475X
2 x 95 mm
2 4)6)
Cable lug
for M8
min. 10 Nm
max. 13 Nm
BM446X
BM466X
BM476X
2 x 185 mm
2 5)6)
Cable lug
for M10
min. 12 Nm
max. 25 Nm
BM447X
BM477X
2 x 185 mm
2 5)
Cable lug
for M10
min. 12 Nm
max. 25 Nm
Wiring diagrams
Instruction handbook b maXX BM4400, BM4600, BM4700
Document No.: 5.12008.07 Baumüller Nürnberg GmbH
192
of 358
7.10
1)
Not short-circuit-proof, consider maximum load! See „Brake resistor external“ in chapter ZTechnical Data–
from page 31.
2)
Not short-circuit-proof, consider maximum load! See „connected load DC link“ in chapter ZTechnical Data–
from page 31.
3)
See „permitted brake resistor continuous power“ in chapter ZTechnical Data– from page 31.
4)
The cable lug may be 25 mm wide at most. The maximum cable diameter is dependent on the cable lug. In
case the cable lug, which you use, can safely clamp a stronger cable than 95 mm
2
, you may also use stronger
cables than 95 mm
2
. Also see ZCables power supply-device– from page 268.
5)
The cable lug may be 35 mm wide at most. The maximum cable diameter is dependent on the cable lug. In
case the cable lug, which you use, can safely clamp a stronger cable than 185 mm
2
, you may also use stron-
ger cables than 185 mm
2
. Also see ZCables power supply-device– from page 268.
6)
One cable of the mentioned cross section is sufficient for the operation.
7)
See also ZExplanation type code– on page 126.
