Installation
Instruction handbook b maXX BM4400, BM4600, BM4700
Document No.: 5.12008.07
219
of 358
7
1)
The analog output speed can be changed from „slow output“ to „fast output“ by the operation software and
vice versa.
BM4-F-AIO-
01 02 03 04
No of inputs 2
No of I/O assignments input 2
Resolution 10 bit / 12 bit 16 bit 12 bit 16 bit
Type Differenzeingang
Input resistance ca. 50 k ca. 100
Max. input current 200 µA 20 mA
Min. input current 4 mA
Sampling rate inputs, one input used 125 µs
Sampling rate inputs, both input used 250 µs
Analog input voltage -10 V bis +10 V 2 V
No of outputs 2
1)
No of I/O assignments output 2
Max. output current 1 mA
Resolution 8 bit 16 bit 12 bit 16 bit
Update rate fast outputs 125 µs
Update rate slow outputs 8 ms
Short-circuit current capability output limited short-circuit proof (max. 10 s)
Analog output voltage -10 V bis +10 V
