Safe stop
Instruction handbook b maXX BM4400, BM4600, BM4700
Document No.: 5.12008.07
337
of 358
E
Different starting / shutdown options BM4X1X to BM4X7X
1)
„yes“, if T
SR pulse enable
= 200 ms
Starting / shutdown condition
BM4X1X BM4X2X BM4X3X BM4X4X BM4X5X BM4X6X BM4X7X
Auxiliary supply (24 V) and 
safety relay 1 + 2 and
power supply 
simultaneously ON
yes yes yes yes yes yes yes
Auxiliary supply (24 V) and 
safety relay 1 + 2 
simultaneously ON
yes yes yes yes yes yes yes
Power supply „OFF“ power
supply „ON“ at pulse inhibit
yes yes yes yes yes yes yes
Pulse enable „ON“ at an activated
safety relay
yes yes yes yes yes yes yes
Pulse enable and 
safety relay 1 + 2 
simultaneously „ON“
no no no no no no no
Pulse enable and 
safety relay 1 + 2 
simultaneously „OFF“
no no no no no no no
Safety relay 1 + 2 “ON“ 
20 ms before pulse enable
yes no
1)
yes yes yes yes yes
Safety relay 1 + 2 “OFF“ 
20 ms after pulse enable
yes no
1)
yes yes yes yes yes
