Detailed Instructions
Page 38 Auto Syringe AS50 Infusion Pump Operator’s Manual 07-19-B3-430
Note: If a protocol has been selected, a default dose may appear automatically. Use ▲
and ▼ or the digit keys to modify this value as necessary, and press
CONFIRM to
complete the data entry.
5. Enter the dose in mg/kg/hr, mg/kg/min, mcg/kg/hr or mcg/kg/min, depending on the
infusion mode selected. Press
CONFIRM to complete the data entry. The pump
automatically calculates and displays the equivalent rate in mL/hr.
Bolus in mg/kg/hr, mg/kg/min, mcg/kg/hr, and mcg/kg/min Modes
Note: If a protocol has been selected, bolus delivery may be disallowed or a default
bolus size may appear automatically. If a default bolus size is displayed, use ▲
and ▼ or the digit keys to modify the value as necessary.
In mg/kg/hr and mg/kg/min modes, bolus size is entered in mg/kg. In mcg/kg/hr and mcg/
kg/min, the bolus size is entered in mcg/kg. The pump automatically calculates the
equivalent bolus size in mL and displays both values. The bolus rate is displayed in mL/hr.
See “Bolus Function” on page 55 for more information on bolus delivery.
Programming Notes
1. The patient body weight range is from 0.01 to 200.0 kilograms (kg). The drug
concentration range is from 0.0001 mg/mL to 100.0 mg/mL. The concentration range
may be further limited for very large or small body weights. The dose limits are
determined by the drug concentration and syringe selection. See “Syringe Data
Tables” on page 25 for minimum and maximum infusion rates for each syringe.
2. The CONC. and BODY WT fields cannot be reprogrammed once the infusion has been
started.
3. Pressing CONFIRM during delivery briefly displays additional program data.
4. A bolus can only be programmed, edited, or delivered after the drug concentration
(
CONC.) has been programmed.
