Configuration
Page 62 Auto Syringe AS50 Infusion Pump Operator’s Manual 07-19-B3-430
To begin reviewing the options within the current group, press CONFIRM to accept the
pending
Y response. The text field will display only the options that are configured. Press
CONFIRM to view each additional option. When the last option in a group has been
displayed, the next option group prompt is displayed (for example:
VIEW SYRINGES).
To skip an option group, press either ▲ or ▼ to change the
Y to N (for “no”). Press
CONFIRM to advance to the next option group.
The following table shows the configuration groups, and the options within each group.
Note: Inactive options are not shown in Configuration Review mode.
Configuration Review Table
To review the Modes group, the initial prompt is VIEW MODES. Answering Y (the default
response) opens up that group for review. Answering N skips that group and prompts for the
manufacturers group (VIEW MFRS).
GROUP PROMPT GROUP SELECTIONS
VIEW LIBRARY List of enabled protocol libraries.
VIEW MODES ML/HR MG/HR MCG/KG/HR
ML/MIN MG/MIN MCG/KG/MIN
UNITS/HR MCG/HR CUSTOM DILUTION
UNITS/MIN MCG/MIN SINGLE DOSE
MUNITS/HR MG/KG/HR MANUAL SCHEDULE
MUNITS/MIN MG/KG/MIN AUTO SCHEDULE
VIEW SYRINGES B-D MONOJECT TERUMO
VIEW DEFAULTS DFAULT LIBRARY DFAULT MODE
DFAULT PROTOCOL DFAULT MFR
VIEW MISC REMOTE CONTROL PSI RANGE AUTO LOCK
LIBRARY AUDIO RANGE SET BACKLITE
SIZE OVERRIDE RATE RANGE ENABLE DB9 PORT
VIEW ALERTS IDLE ALARM BOLUS COMPLETE VOLUME LIMIT
NEAR END DOSE COMPLETE
