07-19-B3-430 Auto Syringe AS50 Infusion Pump Operator’s Manual Page 71
IV Pole Loop
The pump includes an IV pole loop built into the top of the pump. This loop may be
swiveled as required, or folded down and out of the way when not in use.
Cleaning
All the external moving parts must be kept clean of sticky films and other foreign
substances.
If spillage onto external surfaces occurs, clean the surfaces immediately
by the method described below.
Routine Cleaning and Disinfection Techniques
Clean or disinfect the exterior of the device with a soft cloth or cotton swabs, sparingly
dampened with any of the recommended cleaning agents listed below. Remove the
rubber bumpers and clean or disinfect them separately.
Remove residual cleaner or disinfectant from all accessible surfaces with a soft cloth or
cotton swabs sparingly dampened with water, and allow to dry before replacing the rubber
bumpers.
!
