Detailed Instructions
Page 42 Auto Syringe AS50 Infusion Pump Operator’s Manual 07-19-B3-430
SINGLE DOSE Mode Programming Notes
1. All time displays use standard time notation: the two digits to the left of the colon show
hours, the two digits to the right show minutes.
2. If either the INFUSE field or the OVER field is edited, the pump treats the result as a
new infusion. As a reminder,
DOSE CANCELED appears for a few seconds.
3. The pump issues a DOSE COMPLETE alarm at the end of the infusion if the Dose
Complete Alarm option is enabled.
4. Bolus operation is not available in this delivery mode.
5. Pressing CONFIRM during delivery briefly displays additional programming data.
Programming MANUAL SCHEDULE Mode
MANUAL SCHEDULE mode is a timed infusion mode for use when a programmed dose
is to be repeated at regular intervals. The infusion is programmed in terms of dose
volume and dose duration, and the time from the start of one dose to the start of the next.
Each dose delivery must be manually initiated.
MANUAL SCHEDULE mode also allows a delay to the start of the first dose, allowing a
time delay before the infusion regimen begins.
1. At the SELECT MODE ▲▼ prompt, use or to display the available infusion mode
selections. Press
CONFIRM to select the desired infusion mode.
2. Use or and CONFIRM as required to select the syringe manufacturer and size.
3. Enter the dose volume (INFUSE) in mL. Press CONFIRM to complete the data entry.
Example: Program the pump to infuse 5 mL over 5 minutes, using a B-D 30 mL syringe.
Stop the infusion when the TOTAL ML field shows that about 2 mL have been delivered.
Now edit the OVER field to 6 minutes (note that DOSE CANCELED appears for a few seconds),
and start the infusion.
When the pump stops after 6 minutes, about 7 mL will have been delivered; 2 mL from the
original infusion, and 5 mL from the edited infusion.
