Additional Functions and Operations
Page 60 Auto Syringe AS50 Infusion Pump Operator’s Manual 07-19-B3-430
Note: Purge volumes are not included in the total, because purged fluid is not intended
to be infused into the patient.
Display totals are rounded up at the digit displayed at the far right.
Expanded Data Display
The status display generally displays only the most important infusion information.
Pressing
CONFIRM when the pump is fully programmed causes the pump to temporarily
display additional program, syringe, and battery voltage information. Press
CONFIRM
again to restore the normal display immediately. If no key is pressed, the normal display
automatically resumes in a few seconds.
Backlight Feature
The status display backlight is lit whenever the charger is connected and the pump power
is on.
Control of the backlight when the charger is not connected is determined by the
SET
BACKLITE
configuration option group. When the charger is not connected and this option
is enabled for use, the pump turns on the backlight for the preconfigured time period
following a keypress.
Example: if a total delivered value is 0.005, the pump displays
0.01. If a total delivered value is
30.15, the pump displays
30.2.
If an accumulated total becomes too large to display (that is, over 999), the field changes to
EEE.
