07-19-B3-430 Auto Syringe AS50 Infusion Pump Operator’s Manual Page 9
Simplified InstructionsC hapter 4
Operation
Refer to the figure below for the location and description of the pump’s operating controls.
The item numbers shown in the figure are referenced throughout the operating
instructions also.
B
o
tt
o
m
Vi
ew
B
ack
Vi
ew
2
5
6
7
14
11
12
1
0
1
5
4
3
1
Fr
o
nt
Vi
ew
8
T
op
T
T
Vi
ew
9
1
3
r
es
t
r
b
y
CA
1. Status Display
2. Plunger Assembly
(Finger Grip, Plunger
Clamp, Plunger Driver)
3. Status Panel
4. Keypad
5. Flange Slot
6. Barrel Clamp
7. Cradle
8. Charger Port
9. IV Pole Loop
10. Pole Clamp Mounting
Pins
11. Battery Cover
12. Pole Clamp Attach
Recess
13. Barrel Clamp Release
Levers
14. ON/OFF Switch
15. DB-9 RS-232 Serial
Communication Port
