BD FACSymphony A5 SE - Control panel

Control panel
Overview
The following figure shows the components in the control panel, which are listed in the table.
Number Component
1 System indicators
2 Fluid control buttons
3 Sample flow rate buttons
4 Sample fine adjust buttons
5 Status screen
6 Mode button
More information
l
Fluidics system (page 15)
l
Optics (page 20)
14 BD FACSymphony™ A5 SE User's Guide
