BeaconMedaes TotalAlert 2 - Labeling; Field Installation Kits

136
6-847718-00 Rev. B00
ITEM MODEL NUMBER DESCRIPTION
7 Console Rough-In
- 6-233010-00 Oxygen
O2 (100 PSI)
- 6-233011-00 Nitrous Oxide
- 6-233012-00 Medical Air
Air (100 PSI)
Lab Air
- 6-233013-00 Vacuum
Lab Vacuum
- 6-233014-00 Nitrogen
- 6-233016-00 Air (ISO)
- 6-233017-00 Vacuum (ISO)
- 6-233018-00 Instrument Air
- 6-233019-00 WAGD
- 6-233020-00 Carbon Dioxide
CO2 (100 PSI)
- 6-233021-00 CO2/O2
- 6-233022-00 O2/CO2
- 6-233023-00 He/O2
- 6-233024-00 O2/He
- 6-233031-00 Argon
Field Installation Kits
ITEM MODEL NUMBER DESCRIPTION
1 Digital Display Module
- 6-290980-10 Oxygen
- 6-290980-11 Nitrous Oxide
- 6-290980-12 Medical Air
- 6-290980-13 Vacuum
- 6-290980-14 Nitrogen
- 6-290980-16 Air (ISO)
- 6-290980-17 Vacuum (ISO)
- 6-290980-18 Instrument Air
- 6-290980-19 WAGD
- 6-290980-20 Carbon Dioxide
- 6-290980-21 CO2/O2
- 6-290980-22 O2/CO2
- 6-290980-23 He/O2
- 6-290980-24 O2/He
- 6-290980-25 Helium
- 6-290980-26 Lab Air
- 6-290980-27 Lab Vacuum
- 6-290980-28 O2 (100 PSI)
- 6-290980-29 Air (100 PSI)
- 6-290980-30 CO2 (100 PSI)
2 Multi-Signal Module
- 6-290981-00 W/O Relays
- 6-290981-RL W/ Relays
Field installation kits include everything required to
replace a blank module with a digital display mod-
ule or a multi-signal module. Digital display module
kits include sensors.
Labeling
ITEM MODEL NUMBER DESCRIPTION
1 6-435000-01 Label Set, Gas ID
2 Label, Gas ID
(20/Sheet)
- 6-435000-10 Oxygen
6-435000-11 Nitrous Oxide
- 6-435000-12 Medical Air
- 6-435000-13 Vacuum
6-435000-14 Nitrogen
6-435000-16 Air (ISO)
- 6-435000-17 Vacuum (ISO)
6-435000-18 Instrument Air
- 6-435000-19 WAGD
- 6-435000-20 Carbon Dioxide
- 6-435000-21 CO2/O2
- 6-435000-22 O2/CO2
- 6-435000-23 He/O2
- 6-435000-24 O2/He
6-435000-25 Helium
- 6-435000-26 Lab Air
- 6-435000-27 Lab Vacuum
- 6-435000-28 O2 (100 PSI)
- 6-435000-29 Air (100 PSI)
- 6-435000-30 CO2 (100 PSI)
- 6-435000-31 Argon
3 6-435985-00 Labels, System
Status, Multi-Signal
4 6-435986-00 Labels, Location,
Digital Module
5 6-435995-00 Label Set, Location,
Panel, Area
Replacement Parts
