BeaconMedaes TotalAlert 2 - Start-Up and Checking (Cont.); Combo Alarm Panel

58
6-847718-00 Rev. B00
Operation
Combo Alarm Panel
Start-Up and Checking (Cont.)
1. Turn on electrical power to alarm
panel.
2. Make following observations:
• POWER ON light illuminates on
front of alarm panel.
• Boot message is shown on
vacuum fluorescent display.
• Alarm modules warm-up for ten
seconds. During warm-up, no
audible or visual alarms activated.
After warm-up, audible and visual
alarms are initiated for any active
alarm.
3. Press MUTE button to silence
audible alarm.
4. Pressurize piping system (medical gas
and vacuum).
5. Make following observations:
• Digital display modules display
actual pipeline pressures or
vacuum levels.
• If digital display module pipeline
pressures and vacuum levels are
within pre-set limits, NORMAL
indicator is illuminated.
• If digital display module pipeline
pressures and vacuum levels are
outside pre-set limits, status
indicators show HIGH or LOW.
• If a fault code is displayed (
-- FF 11 --
,
-- FF 22 --
,
-- FF 33 --
or
-- FF 44 --
) refer to
Troubleshooting Guide.
Browse at: http://
TA2_12345
Version: [VERSION]
SN 12345
BeaconMedaes
TotalAlert 2 System
Booting...
• Multiplexer modules indicate current
status from dry-contact switches.
• Connected, but unprogrammed
signals are shown on the vacuum
fluorescent display.
Unassigned
Input [INPUT NUMBER]
