22
6-847718-00 Rev. B00
Combo Alarms
Installation Overview
1. Install alarm panel back box (Page 23).
2. Install remote sensor back box
(Page 24).
3. Pipeline connections (Page 25).
4. Pull wire (Page 27).
5. Power supply wiring (Page 30).
6. Breakout board input wiring (Page 32).
7. Relay board wiring (Page 33).
8. Front panel installation (Page 40).
9. Remote sensor wiring (if required)
(Page 31).
10.Remote sensor installation (Page 42).
11. Ethernet wiring (Page 37).
12.Digital display module master/slave
wiring (if required) (Page 35).
13.Digital display module high/low relay
wiring (if required) (Page 36).
14.General fault/Aux Relay wiring (if
required) (Page 36).
15.Building automation system wiring (if
required). (Page 37)
16.Labeling (Page 43).
