BeaconMedaes TotalAlert 2 - Set-Up Procedures (Cont.); Digital Display Module-Advanced

66
6-847718-00 Rev. B00
Operation
Digital Display Module-Advanced
Two additional levels of “advanced” set-up
features are available.
The first advanced level,
SS EE TT 22
, is used to
adjust communication related parameters.
Changing Communication Parameters
AA DD DD RR
(network address)
A network address uniquely identifies each
digital display module in the alarm panel.
Address range is
00
to
22 55 55
.
For TotalAlert 2 alarm panels, this setting is
programmed at the factory when the alarm
panel is assembled and should not be
changed.
BB AA UU DD
(baud rate)
Used to set communication speed. User
choices are
44 88 00 00
or
99 66 00 00
.
Baud rate must be set to
99 66 00 00
. for
TotalAlert 2 alarm panels.
NN DD FF
(network data format)
Defines data word length. Choices are
88
(bits) or
11 66
(bits). NDF must be set to
11 66
for TotalAlert 2 alarm panels.
PP DD FF
(pressure data format)
Defines data word length transmitted to a
slave alarm panel. User choices are
88
(bits) or
11 66
(bits). Factory setting is
11 66
.
Set-Up Procedures (Cont.)
1. Press and HOLD SETUP button for
TWO seconds until
SS EE TT 22
is displayed.
2. Press and release TEST button on
front of alarm panel.
AA DD DD RR
will be
displayed for one second and then
current network address. Select
desired address by pressing ! or "
buttons.
Each module must have a unique
address.
3. Press and release TEST button.
BB AA UU DD
will be displayed for one second
and then current baud rate. Select
desired baud rate by pressing ! or
" buttons.
4. Press and release TEST button.
NN DD FF
will be displayed for one second and
then current network data format.
Select desired data format by
pressing ! or " buttons.
5. Press and release TEST button.
PP DD FF
will be displayed for one second and
then current pressure data format.
Select desired data format by
pressing ! or " buttons.
6. Press and release TEST button to
save changes.
DD OO NN EE
will be
displayed for two seconds.
7. Digital display module will return to
monitoring mode.
NOTE:
If module is idle for more than one minute dur-
ing set-up procedure, module will chirp three
times, return to monitoring mode and will
default to previous settings. No changes to
settings will be saved.
Set-up must be completed and module must
display
DD OO NN EE
in order for changes to be
saved.
CAUTION:
Communication parameters are factory set and
should not be changed. These instructions are
provided for programming replacement modules.
